Standard Configuration
Optical System: Greenough Optical System
Variable Observation Angle: 6°～66°
Stereo Angle: 10°
Zoom Method: Switchable Between Continuous Zoom and Detent Zoom
Zoom Range: 0.57X–4.68X
Zoom Ratio: 1:8.2
Eyepiece: PL10X/22 Diopter-Adjustable Eyepiece
Camera Eyepiece: Built-in Integrated 0.41X
Maximum Image-Side Field of View: φ22 mm
Objective Lens Optical Path Configuration: 3-Element, Including Protective Glass
Maximum Object-Side Field of View: φ38.5 mm
Working Distance: 115 mm
Stand Adapter Hole Diameter: Φ76 mm
Binocular Interpupillary Distance Range: 42 mm–120 mm
Eyepiece Tube Diameter: Inner Diameter φ30 mm, Parfocal Distance 10 mm
Image Output Optical Path: Simultaneous Imaging
Built-in Camera (Optional): 1/1.7", 4K Ultra-HD Digital Camera
