Standard Configuration
Optical System: Parallel Optical Path System
Variable Observation Angle: 0°–45°, Rotates 360° Around the Optical Axis
Zoom Method: Detent Zoom
Zoom Range: 0.7X–4.5X
Zoom Ratio: 1:6.4
Eyepiece: PL10X/22 Diopter-Adjustable Integrated Eyepiece
Camera Eyepiece: Built-in Integrated 0.45X
Maximum Image-Side Field of View: φ22 mm
Objective Lens Optical Path Configuration: 4-Element, Infinity-Corrected System
Maximum Object-Side Field of View: φ43.9 mm (0.75X)
Working Distance: Standard 130 mm (0.75X)
Stand Adapter Hole Diameter: Φ76 mm
Binocular Interpupillary Distance Range: 48 mm–75 mm
Eyepiece Tube Diameter: Inner Diameter φ30 mm, Parfocal Distance 10 mm
Image Output Optical Path: Simultaneous Imaging
Built-in Illumination: 128 High-Brightness LED Lights with 8-Zone Illumination, Capable of Achieving Polarized Illumination
Multifunctional Display: 8-Zone Illumination / Light Source Brightness / Magnification Display / Startup Screen, etc.; 1.3-Inch Screen, 240 × 240 Pixels
Built-in Camera (Optional): Built-in 1/1.8" 4K Ultra-HD Digital Camera
